Basic Info.
Model NO.
CDM-8099
Moisture Content
<0.15 %
Mobility Resistance
5
Light Fastness
4-8
Migration Resistance
5
Heat Resistance
5
Transport Package
25kg Kraft Bag
Specification
20%-80% Color Content
Trademark
Chuangda
Origin
China
HS Code
3902100090
Production Capacity
5000t/Month
Product Description
PP Non-woven Fabrics Plastic Colorful PP Masterbatch
Technical parameter:
Package: 25kgs Kraft Bags
Technical Specification: SGS Certificate
Applications of color masterbatch:
1.Injection Molding (Box, Containers, Chairs, Crates, Buckets, Battery, cases, Hangers, etc.)
2.Injection Molding (Automotive, Electronic, Construction, House wares, Furniture, Toys, etc.)
3.Extrusion Molding (Sheet, Pipe, Wire & Cable, etc.)
4.Film (shopping bags, casting film, multilayer film, etc.)
5.Fiber (Carpet, Textiles, Upholstery, etc.)
6.Blow Molding (Medical & Cosmetic Container, Lubricant & Paint Container, etc)
FAQ:
Q1. How to use masterbatch?
A: just mix up with the resin granules according to the dosage ratio under appropriate temperature.
Q2. The difference between the general use and the special purpose masterbatches?
1: Special purpose masterbatch: used as the same material as carrier. For example, PE products often use master batches based on PE.
2: General use masterbatch: Use one resin as carrier, but also can be used for coloring other resins.
In general, it's easy to use this masterbatch but there are some shortcomings:
A. Poor predictability of the color.
The final color changes according to the change of resin.
B. Affect other characters of plastic products.
Especially the hardness of products for it's easy to be deformed and distorted, especially for engineering plastic
C. Higher cost
General use masterbatches often use pigments which have higher heat resistance grade and higher cost.
Q3. How long the masterbatch could be stored?
A : If stored under a dry and cool environment, the quality of masterbatches will not change even after a long period of store, for the pigments fixed on the carrier resin which stay in a closed state.
Q4. Does the masterbatch need to be dried before use?
A : In general it can be used directly except ABS and some expecial masterbatches mentioned, which should be dried according to common method.
Q5. Does the masterbatches influence the property of products?
A : Some pigments have effect on flame resistance. It should be mentioned as first if is used for flame resistance products.
Q6. Does the mould have an effect on masterbatches?
A : If ask for a smooth surface, Good quality mould is needed.
Technical parameter:
| ITEMS | Nominal Value Unit |
| Specific Gravity | 0.95~1.14 |
| Melt Mass-Flow Rate(MFR)(190ºC/10.0kg) | <15 g/10min |
| Carbon Black Content | 40 % |
| Moisture Content | <0.15 % |
| PE Carrier | 52% |
| PE wax | 8% |
| Production Temperature | 150-180ºC |
| Mobility Resistance | 5 |
| Light Fastness | Grade 4-8 |
| Migration Resistance | ≥4 |
| Heat Resistance | ≥4 |
| Add Ratio | 2%-10% |
